The Elite NEX White power supply unit is a dependable choice for entry level users and system integrators. The quiet 120mm fan, Active PFC, and 3 years warranty deliver a PSU that provides function you can count on. This power supply unit has been engineered for reliability. The Elite NEX is a complete solution, offering performance and stability at an affordable price.
TECHNICAL SPECIFICATIONS
| ATX Version | ATX12V Rev. 2.41 |
| PFC | Active PFC |
| Input Voltage | 200 - 240V |
| Input Current | 5A |
| Input Frequency | 50 - 60Hz |
| Dimension (L x W x H) | 140 x 150 x 86mm |
| Fan Size | 120mm |
| Fan Bearing | Sleeve Fan |
| Efficiency | >= 85% @ Typical Load |
| ERP 2014 LOT 3 | Yes |
| Operating Temperature | 0 - 40°C |
| Power Good Signal | 100 - 500 ms |
| Hold Up Time | >= 10ms at 100% Load |
| MTBF | >100,000 hours |
| Protections | OVP / OPP / SCP / UVP / OTP / Inrush Protection |
| Regulatory | TUV,cTUVus,CE,FCC,CCC,EAC,UKCA |
| ATX 24-pin Connnectors | x1 = 1x (550mm) |
| EPS 4+4 Pin & EPS 8Pin | x2 = 1x [550(8Pin)+120(4+4Pin)mm] |
| SATA Connectors | x2 = 1x (400+150mm); x3 = 1x (400+150+150mm) |
| Peripheral 4-pin Connectors | x3 = 1x (400+150+150mm) |
| PCI-E 6+2 pin Connectors | x2 = 1x (500+120mm) |
