TECHNICAL SPECIFICATIONS
| Model | CARDEA II |
| Color | Red |
| Interface | PCIe 3.0 x4 with NVMe 1.3 |
| Capacity | 512GB |
| Voltage | DC +3.3V |
| Operation Temperature | 0°C ~ 70°C |
| Storage Temperature | -40°C ~ 85°C |
| Terabyte Written | 256GB / 380 TB 512GB / 800 TB 1TB / 1,665TB |
| Performance | Crystal Disk Mark: 256GB Read/Write: up to 3,000/1,000 MB/s 512GB Read/Write: up to 3,400/2,000 MB/s 1TB Read/Write: up to 3,400/3,000 MB/s IOPS: 256GB Read/Write: 200K/200K IOPS Max 512GB Read/Write: 350K/300K IOPS Max 1TB Read/Write: 450K/400K IOPS Max |
| Weight | 45g |
| Dimensions (L x W x H) | 80.1 x 23.4 x 12.9 mm |
| Humidity | RH 90% under 40°C (operational) |
| Vibration | 80Hz~2,000Hz/20G |
| Shock | 1,500G/0.5ms |
| MTBF | 2,000,000 hours |
| Operating System | 1. System Requirements: Windows 10 / 8.1 / 8 / 7 / Vista Linux 2.6.33 or later 2. This product has a heat sink, recommended the use of desktop only. |
| Warranty | 3-year limited warranty (Limited offer 5 Years Warranty) |
