TECHNICAL SPECIFICATIONS
Capacity | 1TB |
NAND Flash | 3D NAND |
Interface | PCIe Gen3 x4 |
Form Factor | M.2 2280 |
MTBF | 2,000,000 hours |
Dimensions (L x W x H) | 80 x 22 x 3.13mm / 3.15 x 0.87 x 0.13inch (with heat sink) 80 x 22 x 2.15mm / 3.15 x 0.87 x 0.09inch (without heat sink) |
Weight | 9g / 0.36oz (with heat sink) 6g / 0.24oz (without heat sink) |
Sequential Read (Max) | Up to 3,500MB/s* |
Sequential Write (Max) | Up to 3,000MB/s* |
4KB Random Read IOPS (Max) | Up to 480K* |
4KB Random Write IOPS (Max) | Up to 260K* |
Operating temperature | 0°C - 70°C |
Storage temperature | -40°C - 85°C |
Shock resistance | 1500G/0.5ms |
Terabytes Written (TBW) | 600TBW** |
Warranty | 5-year limited warranty*** |
Note | * Performance may vary based on SSD capacity, host hardware and software, operating system, and other system variables. ** The value is the minimum amount of terabyte written that could be reached. *** The SSD is based on the TBW or Warranty period. Visit www.adata.com/en/support/consumer?tab=warranty&warranty=warrantyService for more details. |
