Specifications
| Key Specifications | |
|---|---|
| Graphics Chipset | NVIDIA H100 |
| Edition | PNY |
| Manufacturing process | 4 nm |
| Microarchitecture | Hopper |
| GPU Name | |
| Cores & Clocks | |
|---|---|
| NVIDIA CUDA Cores | |
| Core Clock | |
| Boost Clock | |
| Video Memory (VRAM) | |
|---|---|
| Memory Size | 80 GB |
| Memory Type | HBM3 |
| Memory Clock | |
| Memory Bit Rate | |
| Memory Bandwidth | 2000 GB/s |
| ECC Technology | No |
| Cooling | |
|---|---|
| Cooling | Passive |
| I/O & Connectivity | |
|---|---|
| Interface | PCIe |
| Interface Bandwidth | 128 GB/s |
| Graphics Output | |
| Visuals | |
|---|---|
| Multi GPU Support | 2-Way NVLink |
| NVLink Support | N/A |
| Total NVLink Bandwidth | 600 GB/s |
| Microsoft DirectX Support | |
| HDCP Ready | No |
| Multi Monitor Support | |
| Concurent Users | N/A |
| H.264 1080p30 Streams | N/A |
| Maximum Digital Resolution | |
| Maximum VGA Resolution | |
| Supported Graphics APIs | |
| Compute Performance | |
|---|---|
| Supported Compute APIs | |
| Single Precision (FP32) Processing | Yes |
| Single Precision (FP32) Performance | 51 teraFLOPS |
| Double Precision (FP64) Processing | Yes |
| Double Precision (FP64) Performance | 26 teraFLOPS |
| Tensor Processing | Yes |
| Deep Learning (Tensor) Performance | 756 teraFLOPS |
| NVIDIA Tensor Cores | |
| Integer Operations (INT8) | 3026 TOPS (Tensor) (Tera-Operations per Second) |
| Ray-Tracing | |
|---|---|
| NVIDIA RT Cores | |
| RTX-OPS | |
| Rays Cast | |
| Power & Thermals | |
|---|---|
| Graphics Card Power Connectors | |
| Board Power | 300~350 W |
| Minimum Recommended PSU | |
| Maximum GPU Temperature | |
| Physical | |
|---|---|
| Form Factor | Dual Slot |
| Low Profile Compatible | No |
| Low Profile Support | |
| Dimensions | |
| Package Type | Retail |
